V6 CLP Lite prints GS-1 standard barcodes and CLP labeling. Dual color in one compact Inkjet printer. Digital Printing for Industry 4.0

Prints small font sizes reducing operational cost. Direct impression on te container at the end of the process.

  • Alt
  • Alt
  • Alt

Characteristics

  • Native resolution of 180 dpi up to 60 m / min
  • Multiple densities and contrasts
  • High quality bar codes. GS-1 standard
  • Intuitive user environment
  • Actual on-screen preview of the message to be printed (WYSIWYG)
  • Oil based and UV LED inks
  • Remote assistance
  • External hardware message selection
  • Integration with post-print bar code reader
  • Scripting for full customisation of jobs

Printable products

Porous, glossy, coated cardboard, paper, textiles, wood, plastic, metal, foam, EPS...

OPTIONS

Encoder, post-printing bar code verification, alarm beacons, bar code reader for selecting products, external message selection.

Advantages

  • Customisation. Short print runs. Promotions
  • Reduction of stock of pre-printed containers
  • Practically zero maintenance
  • No stoppages to change consumables
  • Alt
  • Alt
  • Alt
  • Alt

UV - LED

Colors live at any speed up to 60m / min.
The polystyrene surface of the box is treated with great delicacy while preserving its delicate properties.

Alt

Videos

Specifications

Print

Print head resolution:
180 dpi
Speed:
0.2 - 192 m/min depending on the resolution
Height:
72 mm
140 mm
Maximum length: +100 metres
Densities: 3 levels
Font type:
True Type ™, Open Type ™ fonts
Character coding: Unicode
Bar codes:
GS-1 standard
EAN/UPC, ITF-14, GS1-128, GS1 Datamatrix,
GS1 QR Code
Printing of variable fields:
Of user (customised fields) and automatic
fields (expiry dates, shift codes, counters)
Orientation:
Vertical (side of the product)
Horizontal (top of the product)
Printing on ramps (consult)

Electrics

Power supply:
Auto-range
88-264VAC /
47-63 Hz, 108 W (max)
Inputs (per block):
1 x printing signal
1 x encoder
Outputs (per block):
2 x programmable
2 x status indicators
Communication ports:
1 x RS-232
1 x Ethernet 10/100
1 x USB
1 x Wi-Fi (Optional)

Other Specifications

Environmental
Work environment:
5 – 40 ºC (41 – 104 ºF)
Protection:
IP 50
User interface
7" colour touchscreen
Selection of messages with preview
WYSIWYG
Diagnostics
Comunications
Own communications protocol
Windows™ Driver
Connectivity with external database and ERP
Remote assistance
Weight:
6 kg. (controller)
5 kg. (L70 motor)
Consumables:
Oil based inks
UV LED inks
Colours:
Black
Black (high contrast)
Cyan
Magenta
Yellow
Other (consult)
